Specifications:

• HDMI input
• Video Resolution - 576i to 1080p
• Video Encoding - H264/AVC
• Audio Encoding - MPEG1 Layer II / AAC
• Connector Type - HDMI Type A
• RF input
• Frequency MHz 5 - 1218
• RF output loss dB 2
• RF Output (= RF Signal Input + HDMI Modulated Transponder)
• Modulated channel frequency MHz 17 - 1218
• Output Level dBµV 59 - 99 (adjustable)
• MER dB Typ. 38
• Output Settings
• Output Type - DVB-T DVB-C ATSC-T ATSC-C DTMB
• Bitrate Mbps 2 - 23 2 - 15 2 - 23
• Channel Bandwidth MHz 6.7 or 8 2 to 8 6 6 6
• Sync frame PN phase
• Basic Setup - Country | Output Type | Output Frequency | Output Level | LCN | Channel Name
• Advanced Configuration - RF | Video & Audio | SID | PMT, VPID, APID | NIT, ONID | PDS | TS ID
• Power - Input voltage: 12 VDC | Consumption: 5 W Typ. (6 W max.) | Jack Ø 2.1 mm
