Characteristics:

Door:

• Indicator light: 1 × green alarm indicator
• Button: 1 × power button

Protection Zone:

• 1-channel dry contact input

Function:

• Tamper alarm: Yes
• Remote update: Cloud update
• Low battery alarm: Yes
• Test Mode: Yes
• Search for: Signal Strength Detection

Communication:

• Wireless
• Carrier frequency: 433.1 MHz–434.6 MHz
• Communication distance: Up to 1,000 m (3,280.84 ft) in open space
• Communication Mechanism: Bidirectional
• Frequency Hopping: Yes
• Encryption mode: AES128

General Specifications:

• Power supply mode: CR123A battery
• Power consumption: Max 70 mW
• Operating temperature: –10°C to +55°C (+14°F to +131°F) (indoor)
• Operating humidity: 10%–90% (RH)
• Dimensions: 100.2 mm × 20.8 mm × 20.3 mm (3.94" × 0.82" × 0.80")
• Package dimensions: 135.0 mm × 98.5 mm × 27.8 mm (5.31" × 3.88" × 1.09")
• Installation mode: Bracket mounting
• Net weight: 70 g (0.15 lb)
• Gross weight: 115 g (0.25 lb)
• Certification: CE

Battery Life:

• 4 years (external input type is NO)
• 2 years (External input type is NC or Pulse)

Material:

• Shell material: PC + ABS

Temperature:

• Measuring range: –15°C to +65°C (+5°F to +149°F) (indoor)
• Measurement accuracy: ±1°C (±1.8°F)
• Resolution: 1°C (33.8°F)
