Main Features:

• Low power consumption
• Low noise figure
• Low phase noise
• High cross-polarization isolation
• High frequency stability
• Very good" test result from the trade journal
• With weatherproof housing

Technical specifications

• Input frequency range: 10.70 – 11.70 GHz / 11.70 – 12.75 GHz
• Output frequency range: 950 – 1950 MHz / 1100 – 2150 MHz
• Outputs: 4 (receiver direct connection)
• LO frequency: 9.75 / 10.60 GHz
• Noise ratio 0.1 dB (typ.)
• Conversion gain: 60dB
• Feed pickup: 40mm
• Operating temperature -30°C ~ 60°C
