MEASUREMENT SCALES:

- AC current: 1000A: ± (2% + 5)

- AC current frequency response: 50Hz ~ 60Hz

- AC voltage: 6V ± (1.2% + 3); 60V / 600V / 1000V: ± (1% + 8)

- DC voltage: 600mV ± (0.8% + 3); 6V / 60V / 600V / 1000V ± (0.5% + 5)

- AC voltage frequency response: 40Hz ~ 400Hz

- Resistance: 600Ω: ± (1% + 3); 6KΩ / 60KΩ / 600KΩ: ± (1% + 2); 6MΩ / 60MΩ: ± (2% + 8)

- Capacitance: 60nF: ± (4% + 25); 600nF/6μF/60μF/600μF: ± (4% + 5); 6mF/60mF: ± (10% + 9)

- Low voltage frequency: 10Hz ~ 1MHz: ± (0.1% + 3)

- High voltage frequency: 40Hz~400Hz

- Duty Cycle (%): 10% ~ 90%: ± (2.6% + 7)

FUNCTIONALITIES:
- True RMS
- Auto / Manual measurement range mode
- LED lantern
- NCV (non-contact voltage detection)
- Diode test
- Checking the continuity of the circuit
- Freeze reading
- Indication of maximum / minimum value
- relative mode
- LCD screen with backlight
- Low battery indication
- automatic shutdown

GENERAL FEATURES:

- Jaw opening: 42mm

- Maximum reading: 6000

- Input impedance (ACV / DCV): ≥10MΩ

- Power: 1.5 V batteries (R03) x 3

- Screen: 43 mm x 45 mm

- Product color: Red and gray

- Product net weight: 465g

- Product Size: 272mm x 81mm x 43.5mm

- Standard accessories: test leads, batteries, carrying case

Brand

Uni-trend

Reference

MT-CLAMP-UT205E
