Main features

• Vandal proof design
• Easy and fast installation
• Real-time video streaming to Android and iOS devices
• Easy connection through the cloud
• High Definition Video
• Motion detection (optional)
• RJ45 Ethernet connection
• Infrared night vision
• Supports ONVIF Protocol

Technical specifications

• Model: D20V400
• Type: Dome
• Coating: Metal
• Vandal Proof Design: Yes
• indoor use: yes
• Outdoor Use: Yes
• Water/dust resistance: IP66
• Resolution: 4MP
• Effective pixels: 2688*1520
• Sensor Type: CMOS
• Lens: 3.6mm
• Sensor Size: 1/3"
• Fixed Focus: Yes
• Viewing angle: 75 degrees
• Infrared LEDs: 18 x 14µ
• Infrared Night Vision Range: ~20m
• IR cut: <10 lux="" li="">
• WDR (Wide Dynamic Range): Yes
• Android / iOS app support: Yes
• Manual exposure setting: Yes
• Manual Image Adjustments: Yes
• White balance: Auto / Manual
• Motion detection: yes
• Email Notifications: Yes
• Support cloud storage: Dropbox / Google (compatible network recorder required)
• FTP Support: Yes
• Privacy Mask: Yes
• Dynamic DNS Support: No-IP, DynDNS, Oray
• Compression: H.265 / H.264 / JPEG / MJPEG
• Stream Profiles: 3 (Main / Sub / Tri)
• Main stream: 2560*1440@20fps / 2304*1296@30fps / 1920*1080@30fps
• Substream: 720*480@20fps / 720*480@30fps
• Tristream: 352*288@20fps / 352*288@30fps
• Network Recorder (NVR) Compatibility: Yes
• ONVIF Protocol Version: 2.4
• Supported protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, SMTP
• Ethernet: 10/100M (RJ45)
• PoE (Power over Ethernet): No
• Power: DC 12V / 500mA
• Operating temperature: -20ºC ~ +60ºC RH95%
• Dimensions (mm): 94.5 x 94.5 x 76
• Weight: 450g
