Specifications:

• Capacity: 1200VA/720W

Prohibited:

• Voltage Range: 162-268Vac / 170-280Vac
• Frequency Range: 50±5Hz or 60±5Hz (automatic detection)
• AC Voltage Regulation (Bat Mode): 220Vac / 230Vac±10%

Exit:

• AC Voltage Regulation (Bat Mode): 220Vac / 230Vac±10%
• Frequency Range (Bat Mode): 50Hz±1Hz or 60Hz±1Hz
• Transfer Time: Typical 4-8ms, 13ms max
• Waveform (Bat Mode): Simulated Sinusoidal Wave

Battery:

• Voltage: 24V
• Number: 7.5AH*2
• Current: 1.0A

Indicators:

• AC Mode: Green LED Light
• Battery Mode: Yellow LED Flash
• Fault: Red LED light

Protection:

• Complete Protection: protection against short circuits, overloads and discharges

Alarm:

• Drum Mode: Sound every 10 seconds
• Low Battery: Sound every second
• Overload: Sound every 0.5 seconds
• Fault: Continuous sound

Physical Parameters:

• Approximate Dimensions LxWxH (mm): 333x130x185
• Approximate Net Weight (kgs): 8.7

Operating Environment:

• Humidity: 0-90% RH@0-40°C (non-condensing)
• Noise Level: = 40dB

Management:

• Communication Port: Possible to choose (USB&RJ45)
