Specifications:

Capacity: 600VA/300W

Prohibited:

Voltage Range: 162-268Vac / 170-280Vac

Frequency Range: 50±5Hz or 60±5Hz (automatic detection)

AC Voltage Regulation (Bat Mode): 220Vac / 230Vac±10%

Exit:

AC Voltage Regulation (Bat Mode): 220Vac / 230Vac±10%

Frequency Range (Bat Mode): 50Hz±1Hz or 60Hz±1Hz

Transfer Time: Typical 4-8ms, 13ms max

Waveform (Bat Mode): Simulated Sinusoidal Wave

Battery:

Voltage: 12V

Number: 7AH*1

Current: 1.0A

Indicators:

AC Mode: Green LED Light

Battery Mode: Yellow LED Flash

Fault: Red LED light

Protection:

Complete Protection: protection against short circuits, overloads and discharges

Alarm:

Drum Mode: Sound every 10 seconds

Low Battery: Sound every second

Overload: Sound every 0.5 seconds

Fault: Continuous sound

Physical Parameters:

Approximate Dimensions LxWxH (mm): 315x100x143

Approximate Net Weight (kgs): 4.2

Operating Environment:

Humidity: 0-90% RH@0-40°C (non-condensing)

Noise Level: = 40dB

Management:

Communication Port: Possible to choose (USB&RJ45)
