Dedicated and Complete, Private Wi-Fi Network in Every Area

Gigabit Ethernet Ports

Wired devices such as VoIP phones can be powered without the need for extra power cables. The four data ports (1 uplink + 3 downlinks) transfer data at gigabit speeds, allowing you to connect multiple devices to your network. One of the downlink ports offers PoE passthrough to eliminate the need for that extra power port.

More Flexible Deployment with PoE

With 802.3af/802.3at PoE support, there's no need for additional cabling. Just plug it into your existing Ethernet cables, and you're good to go.

• Transmit power: <20 dBm (2.4 GHz), <23 dBm (5 GHz band1 & 2), <26 dBm (5 GHz band3)
• Frequency: 2.4GHz, 5GHz
• Antenna: 3 dBi (2.4 GHz), 4 dBi (5 GHz)
• Maximum signal rate: 574 Mbps (2.4 GHz), 2402 Mbps (5 GHz)

• Ethernet Port: 4 Gigabit RJ45 Ports (1 uplink, 3 downlink)
• Power Supply: 802.3at PoE, 48V Passive PoE (PoE adapter included)
• Power consumption: 12W

• Web Management: HTTP/HTTPS
• Management via App: Omada App, version 4.0 or higher
• SNMP: Support v1, v2c, v3

• Operating temperature: 0°C to 40°C
• Certifications: CE, FCC, RoHS

• Dimensions: 143 × 86 × 42.6 mm
• Weight: 185 g

• Included: TP-Link EAP655, Mounting Kits, Installation Guide

Brand

Tp-link Omada

Reference

EAP655-WALL

Stock Online

Low stock

Stock Store

Low stock

Color

White

Ethernet LAN Speed

Wi-Fi Speed

Dual-Band

Yes

GHz

2.4 / 5
