Specifications:

• Code: 9040052
• Outputs : 2
• Bands: RP (0–65 MHz) / VHF/UHF (86–862 MHz)

Band Features:

• Gain (RP): -4.5 ±0.5 dB
• Gain (VHF/UHF): 25 ±1.5 dB
• Flatness Response (RP): ±0.5 dB
• Flatness Response (VHF/UHF): ±1.5 dB
• Gain Adjustment (VHF/UHF): 15 dB (VHF), 10 dB (UHF)

Output Level:

• Max. (DIN 45004B): 105 dBμV
• IMD3 -60 dB: 102 dBμV
• IMD2 -60 dB: 90 dBμV
• CTB -60 dB: 89 / 84 / 90 dBμV

Other Technical Data:

• Return loss: 10 dB
• Noise figure: 6 dB
• Supply voltage: 230V~ ±10% (50/60Hz)
• Power consumption: 5.5 VA
• Operating temperature: -5ºC to +60ºC
• Protection rating: IP20

Brand

ALCAD

Reference

9040052

Stock Online

Available

Stock Store

Available

No. out

2
