Performance:

• Type: IP security camera
• Installation supported: Indoor and outdoor
• Connectivity technology: Wired
• PTZ control (Pan/Tilt/Zoom): Yes
• Remote View: Yes
• Built-in Processor: Yes
• Infrared cut filter: Yes
• Regulatory Approvals: FCC, IC, CE

Design:

• Form Factor: Dome
• Installation type: Ceiling
• Product Color: Black
• Dual LED display: Activity, Link
• Product body material: Aluminum, Polycarbonate (PC), Stainless steel
• Protection Features: Vandal-proof
• International protection code (IP): IPX4
• IK code: IK08
• Weather resistant: Yes

Camera:

• Field of view angle: 360°

image sensor:

• Image sensor type: CMOS

Lens system:

• Number of lenses: 1

Night mode:

• Night version: Yes
• LED type: IR

Video:

• Maximum Resolution: 1920 x 1920 pixels
• Total Megapixels: 5 MP
• Compression formats: H.264, M-JPEG
• Up to 30 frames per second: 30 fps

Audio:

• Built-in Speakers: Yes
• Built-in Microphone: Yes

Network:

• Ethernet LAN: Yes
• Ethernet interface type: Gigabit Ethernet
• WiFi: No
• Bluetooth: No
• live view: yes

Storage media:

• Flash memory size: 8000 MB

Connectivity:

• Number of Ethernet LAN ports (RJ-45): 1

Management features:

• Web-based management: Yes
• reset button: yes

Power management:

• Power supply type: DC, PoE
• Power consumption (max): 8.64 W
• DC output in volts: 48

Environmental conditions:

• Ambient temperature: -20 - 40 °C
• Relative humidity range: 10 - 90%

Weights and dimensions:

• Unit Height: 49mm
• Diameter: 14.7cm
• Product Weight: 655g

Package content:

• Number of chambers: 1
• User Manual: Yes

Reference

UVC-AI-360
