The device detects smoke through a camera with a photoelectric sensor. An additional chemical element detects carbon monoxide and triggers the alarm.
Functionalities
It can work independently from the hub, issuing a fire alarm via an integrated siren. Several detectors indicate an alarm at the same time.
Installation and configuration
Ready to work out of the box: the battery is already installed, so there is no need to disassemble the detector. With one click, it can be connected to the hub in the mobile app. It can be mounted on the SmartBracket in just a few minutes.
Technical specifications:
Intern use
Sensitive Element Photoelectric Sensor for Smoke Detection
Temperature alarm signal at 60 °C
Carbon Monoxide (CO) Detection
Sound and light alarm type
Built-in siren volume 85 dB
Radio signal power 20 mW
Compatibility: Works with all Ajax hubs, repeaters, ocBridge Plus, uartBridge
Jeweler Communication Protocol
Maximum distance between detector and control unit up to 2,000 meters (in an open area)
This product complies with European legislation, namely the new Regulation (EU) 2023/988 of the European Parliament and of the Council of 10 May 2023 on General Product Safety (GPRS) which repealed Directive 2001/95/EC on general product safety and Directive 87/357/EEC on products imitating food.
