Extending the range of radio communication

Verification of alarms with photographs

ReX 2 works with MotionCam and MotionCam Outdoor motion detectors. When activated, they take a series of animated photographs, helping to assess the situation in the facilities. This reduces unnecessary patrol dispatches and gives customers peace of mind.

Radio communication through steel and concrete

With the OS Malevich 2.13 operating system update, the ReX 2 repeater will connect to the hub not only via radio but also via Ethernet using the cable as the only or additional communication channel. A single Ajax system can cover a facility such as an office center with underground parking; a metal hangar with several sections or a warehouse complex composed of several large buildings.

metal warehouse:

Factory complex:

Underground parking:

Improved security system

The ReX 2 works as an additional smart control panel: it connects devices in a self-contained group and takes control at the right time. Thanks to automatic signal strength adjustment, and frame synchronization, any number of devices can be connected to the ReX 2 — communication reliability will not be affected. If, for whatever reason, radio communication with the hub is interrupted, ReX 2 will continue to function via Ethernet. If an Ethernet link is lost, the ReX 2 receives an alarm from a detector and activates a siren to draw attention to the incident and deter the thief.

Ready to resist attacks from intruders

ReX 2 is protected from both software and hardware attacks. It works on OS Malevich operating system, which is immune to viruses. All data transmitted by the repeater is encrypted. Thanks to the built-in backup battery, a sudden power failure in an installation will not be a problem.

Specifications:

• - Classification: Radio Channel Repeater
• - Device Type: Wireless
• - Installation method: Indoor
• - Compatibility: Hub 2 and Hub 2 Plus with OS Malevich version 2.12 and above
• - Alarm signal transmission time: 0.3 seconds
• - Maximum connected devices (in a system with a repeater): Hub 2 — up to 99 / Hub 2 Plus — up to 199
• - Number of repeaters connected to the hub: 5
• - Operating system: OS Malevich
• - Power supply:
• 110−240 VAC or 12 V from 12V PSU to Hub 2/Hub 2 Plus/ReX 2
• .Integrated Li-Ion Backup Battery 2 Ah (Up to 38 hours battery backup)
• - Jeweler radio protocol:
• .Communication range with hub — up to 1700m in open space
• .Communication range with detectors — up to 1700 m in open space, depending on the .detector model
• .Bidirectional connection between devices
• .Operating frequencies — 868.0–868.6 MHz
• .Automatically regulated radio signal power — up to 25 mW
• .Lock cipher encryption based on AES algorithm
• .Detector Ping Interval — 12−300 seconds
• .Frequency Hopping
• - Operating temperature range: Between −10°C to +40°C
• Operating humidity: Up to 75%
• - Anti-sabotage:
• .Fraud protection
• .Notification of inhibition
• Tamper Resistant
• - Dimensions: 163 × 163 × 36 mm
• - Weight: 330g
• - Warranty: 24 months from the date of sale
