Specifications:

• Power Supply: 220–240V (1 Phase ~ 50Hz) / Outdoor Unit

Performance:

Cooling Capacity:

• Capacity: 7.1(1.11-7.8)kW | 24226(3412-26614)BTU/h
• Consumption: 2400(450-3350)W
• Current: 11.1(2.1-16.4)
• SEER: 6.1 W/W
• EER: 2.96 W/W
• Energy Classification: A++
• Annual Consumption: 321kWh

Heating Capacity:

• Capacity: 7.1(1.37-8.2)kW | 24226(3412-26614)BTU/h
• Consumption: 2200 (450-3350)W
• Current: 10.1(2.1-16.8)A
• SCOP: 4 W/W
• COP: 3.23 W/W
• Energy rating: A+
• Annual consumption: 1677kWh

Features:

Indoor Unit:

• Sound power (SH/H/L/SL) dB: 59/54/51/44
• Sound pressure (SH/H/L/SL) dB: 46/43/40/24
• Air flow (SH/H/L/SL) m3/h: 1200/1050/900/800
• Selectable temperature ºC: 16 - 32

Outdoor Unit:

• Sound power dB: 65
• Sound pressure dB: 55
• Air flow m3/h: 2850
• Operating temperature ºC: -15~53
• Compressor: Type: Rotary Brand: SANYO
• Refrigerant: Type/Load R32/kg: 1.5 Extra charge g/m: 15

Dimensions and Weight:

Indoor unit:

• Net dimensions (W×H×D) mm: 1025 x 319 x 223
• Gross dimensions (W×H×D) mm: 1102 x 395 x 305
• Net/gross weight kg: 13/15

Outdoor unit:

• Net dimensions (W×H×D) mm: 820 x 635 x 310
• Gross dimensions (W×H×D) mm: 969 x 688 x 402
• Net/gross weight kg: 36.7/40.7

Connections:

Cooling tube:

• Liquid–Gas In.: 3/8" - 5/8"
• Max. length m: 25
• Max. elevation m: 15

Electrical Connections:

• Power source mm: 2 x 2.5 + T
• Interconnect mm: 4 x 2.5

Brand

HTW

Reference

S071OEM3

Stock Online

Low stock

Stock Store

Low stock

BTUs

24.000
