Technical Specifications

• Main Processor: ARM Cortex A7 Quad-core
• Operative System: Embedded Linux

• Video
• Input type: Analogue (4 x BNC) + IP
• Input standard: Analogue / AHD / CVI / TVI 2.0 / Network
• Output: 1 HDMI, 1 VGA

• Alarm
• Sensor Input: No
• Output: No
• Motion detection: 9 channels
• Email alarm: Yes

• Display
• VGA: Resolution: 1024x768, VGA, 1280×720, 1280×1024,
  1920×1080
• HDMI: Resolution: 1024x768, VGA, 1280×720, 1280×1024,
  1920×1080
• Display split: 9 Channel  / 4 Channel / 1 Channel
• OSD: Camera Title, Time, Video Loss, Recording, Motion Detection

• Recording
• Video compression: H.265/H.264
• Resolution: 4k(4096×2160), 5MP(2592×1944), 4MP(2688×1520), 3MP(2048×1536), 1080P (1920×1080), 960P (1280x960)
• Record rate: PAL: 4k@5×25fp, 5MP@8×25fp, 4MP@9x25fp, 3MP@9×25fp, 1080P@9×25fp, 960P@9×25fp, 720P@9×25fp, D1@9×25fp / NTSC: 4k@5×30f-p,5MP@8×30fp, 4MP@9×30fp, 3MP@9×30fp, 1080P@9×30fp, 960P@9×30fp, 720P@9×30fp, D1@9×30fp
• Record mode: Manual / Timer / Motion Detection

• Playback & Backup
• Remote Sync Playback: Yes
• Search Mode: ALL, Channel, Manual, Time, Date, Motion Detection - Play, Pause, Stop, Rewind, Fast play, Slow play

• Network
• Interface: 1 x RJ45 (10M/100M Adaptive Ethernet Interface)
• Network functions: HTTP, TCP/IP, IPv4, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, DDNS, FTP, IP Search, P2P
• ONVIF version: Support Onvif 2.4
• Web browser: IE6-11, Firefox (IE Tab)
• PoE (Power over Ethernet): No
• Cloud support (P2P): Yes

• Hard disk driver
• Interface type: 1 SATA Interface, 2.5”/3.5” SATA
• Capacity: Up to 6TB capacity

• General
• Language: Chinese, English, Polish, Czech, Russian, Thai, Hebrew,
  Arabic, Bulgarian, Farisa German, French, Portuguese,
  Turkic, Spanish, Italian, Hungarian, Romanian, korean, Dutch, Greek
•  USB Interface: 2 USB 2.0 Interfaces
• Power supply: DC12V/2A
• Working Environment: -10~55°C/10~90%
• Dimension (W×D×H): 219*217*40(mm)
• Weight: 2.0KG (without HDD)
