SSD M. 2 2280 KIOXIA EXCERIA PLUS -1TB - PCIe NVMe - LRD20Z001TG8

Game-Changing Performance

The KIOXIA EXCERIA PRO series offers impressive speeds of up to 7,300 MB/s sequential read and up to 6,400 MB/ s sequential write, significantly reducing load times in games and video editing processes.

Small and Compact for an Easy Upgrade

Featuring a thin-faced M.2 2280 form factor, EXCERIA PRO Series SSDs connect directly to the motherboard, simplifying the system upgrade process without having to deal with additional cables.

• Capacity: 500GB, 1TB, 2TB
• Form factor: M.2 type 2280-D3-M
• Interface: PCI Express® Base Specification Revision 3.1a (PCIe®)
• Flash memory type: BiCS FLASH™ TLC
• Maximum interface speed: 32 GT/s (PCIe® Gen3x4L)
• Dimensions (maximum: LxWxH): 80.15 x 22.15 x 3.73 mm
• Interface Command: NVM Express™ with Command Set Revision 1.3c Architecture
• Weight: 10.0 g (typ.)

• Maximum sequential read speed*1: 3,400 MB/s
• Maximum sequential write speed*1: 3,200 MB/s
• Maximum random read speed*2: 500GB: 650,000 IOPS
• 1TB, 2TB: 680,000 IOPS
• Maximum random write speed*2: 500GB: 600,000 IOPS
• 1TB, 2TB: 620,000 IOPS
• Endurance: TBW*3: 500GB: 200TB
• 1TB: 400TB
• 2TB: 800TB
• MTTF: 1.5 million hours

• Operating Temperature: 0 ℃ (Ta) to 85 ℃ (Tc)
• Storage Temperature: -40℃ to 85℃
• Certification: Compliant with RoHS*5
• Shock resistance: 9.806 km/s2 {1 000 G} 0.5 ms average sine wave
• Vibration: 196 m/s2 {20 G} Peak, 10~2 000 Hz, (20 min / eje) x 3 ejes
• Supply voltage: 3.3 V ±5 %
• Power consumption: PS3: 50 mW (typ.)
• PS4: 5 mW (typ.)
• Power consumption (active): 500GB: 6.7W (typ.)
• 1TB: 6.7W (typ.)
• 2TB: 7.6W (typ.)

• PCI Express: Compatible with PCI Express® Base Specification Revision 3.1a and NVM Express™ Revision 1.3c command set
• Connector Type: M.2 M Main Jack
• Target applications: Client desktops and laptops

Service and support: 5-year manufacturer warranty*4

Performance optimization: TRIM, Idle Time Garbage Collection
