Amiko Indoor Wi-Fi Video Surveillance Kit 2MP – WIFI-CS200W

Technical specifications:

* 2 MP smart wifi IP camera:

- Image sensor - 1/3" SONY low light CMOS sensor

- Resolution - 2MP 1080P

- Effective pixels - 1920 (H) * 1080 (V)

- Compression - H.264 / H.264 + / H.265 / H.265 +/- JPEG / AVI / MJPEG

- TV System - PAL / NTSC

- Electronic shutter time:

»Auto - PAL 1 / 25-1 / 10000Sec

»NTSC-1 / 25-1 / 10000Sec

- S/N Ratio: ≥52dB

- Digitization system - Progressive

- Video output - Network

- Reset button - Optional

* Lens Type:

- Focus length - 3.6mm

- Focus control - Fixed

- Lens Type - Fixed

- Pixels - 3M Pixels

* Night vision:

- Infrared LED - 42μ x 2PC

- Infrared distance - 30M

- Infrared status - Automatic control

- IR power on - Automatic control

* NVR 4CH WIFI Full HD:

- Main processor - ARM Cortex A7 processor

- Operating system - Embedded LINUX

- Video:

» Input - 4CH (2592x1944, 2048x1536, 1920 × 1080, 1280 × 960, 1280 × 720, etc)

» Output - 1 VGA, 1 HD

- Audio:

" Prohibited - /

» Output - 1 RCA port (Linear, 1kΩ)

» Audio bitrate - 64 kbps

»Audio compression standard - G711u, G711a, G726

- Alarm:

» Sensor input - NO

»Exit - NO

» Motion detection - 4 channels, MD zones: 396 (22 × 18)

»Trigger Events - Recording, Email, FTP, Snapshot, Buzzer and On-screen Alert, Alarm output

- Network:

»Interface - 4xRJ45 (1xWAN + 3xLAN) Adaptive ethernet interface 10M / 100M

»Input Bandwidth - 28MB

» Network Functions - TCP/CP, HTTP, UPnP, DNS, NTP, SMTP, PPPoE, DHCP, FTP, DDNS, RTP, RTSP, RTCP, p2p

»Onvif Version - Onvif Support 2.4

» Web Browser - IE8-11, Google Chrome (less than Ver. 44), Firefox (less than Ver. 53)

» CMS Software - Support Windows 7 / Windows 8 / Windows 10

» Cloud support - (P2P)

» Smart Phone - iPhone, iPad, Android, Android Pad

"PUT - /

»Wi-Fi - Support

» WIFI range - No obstacles 300m Max.

- Storage:

» Interface type - 1 SATA hard disk interface

»Capacity - (2.5" / 3.5" SATA) Capacity up to 8TB

Kit Content:

- NVR - 1 x SCNVR 4CH WIFI FULL HD (recorder)

- Camera - 2 x SC25M200 WIFI PIR (with PIR detector); 1 x SC25M200 WIFI SMOKE (with gas detector); 1 x SC25M200 WIFI SOUND (with audible alarm)

- WIFI strip - No obstacles 300mts

- Mouse - 1 x USB 2.0 mouse

- Adapter - 1xDC 12V 2A for WIFI NVR, 4xDC 12V 0.5A for WIFI IP camera

- Weight - 5.6 kg / whole kit
