1200MBPS WI-FI, FAST AND NICE INTERNET

AC12 creates reliable and high-speed Wi-Fi network, powerful 802.11ac Wi-Fi standard, 3x faster than Wireless N. More and more devices use ac standard, thus can offer Wi-Fi performance at its full potential. With its wireless speed, the AC12 is the superior choice for faster Wi-Fi.

STRONG SIGNAL, GREAT COVERAGE

Four external 5dBi antennas powered with advanced antenna technology provide users with greater wireless coverage and Wi-Fi signal strength throughout their home or office, making weak connections and dropped connections a thing of the past.

EASY PARENTAL CONTROL AND ACCESS CONTROL

Supervise users so that they have responsible access, under the control of parents or administrators. Establish a list of websites that are allowed or blocked from being accessed. Allow guests to access your Wi-Fi network and protect your privacy at the same time. Make sharing easy, keep it safe.

EASY INSTALLATION IN THREE STEPS

With hassle-free setup, you can simply follow the step-by-step instructions on the setup page to set up your AC12 in minutes.

Specifications:

-Dimensions: 222mm x 140mm x 32mm

-External Power Supply: 9VDC/0.85A

-Antenna: 4 Omnidirectional Antennas of 5dBi

Signal Rate

-11ac: Up to 867Mbps (Dynamic)

-11n: Up to 300Mbps (Dynamic)

-11g: Up to 54Mbps (Dynamic)

-11b: Up to 11Mbps (dynamic)

-Buttons: Reset button

-Wireless standards: IEEE 802.11ac, IEEE 802.11n, iEEE 802.11g, IEEE 802.11b, IEEE 802.3, IEEE 802.3u

Frequency:

-2.390 ~ 2.4835GHz

-5150 ~ 5825GHz

Reception Sensitivity

-11b CCK 1 -96

-11g OFDM 6 -93

-11n HT20 MCS7 -73

-11n HT40 MCS7 -70

-11a OFDM 6 -92

-11ac VHT20 MCS8 -68

-11ac VHT40 MCS9 -64

-11ac VHT80 MCS9 -60

Interfaces

-4 10/100Mbps LAN ports

-1 10/100Mbps WAN port

-Certifications: CE, ROHS

package content

-Ac1200 Dual Band Wireless Router

-Power supply

-Quick Installation Guide

-Ethernet cable

Environment

-Operating Temperature: 0⁰C ~ 40⁰C (32⁰F ~ 104⁰F)

-Storage temperature: -40⁰C ~ 70⁰C (-40⁰F ~ 158⁰F)

-Operating humidity: 10%~90%, non-condensing

- Storage humidity: 5%~90%, non-condensing

-Transmission Power: <20dBm

-Wireless Security: WPA-PSK / WPA2-PSK

-WAN Type: Dynamic IP/Static IP/PPPoE

-Management

-Access control

-Local Management

-Remote Management

-DHCP: Server

-Port Forwarding: Virtual Server, UPnP, DMZ

-Dynamic DNS: Oray

-Firewall: IP and MAC Address Binding

-Protocols: IPv4

-Guest Network: 2.4GHz Guest Network
