Specifications:

• Switch type: Managed
• Switch layer: L2
• Support for Quality of Service (QoS): Yes
• Web-based management: Yes
• Traffic Classification: Yes
• MIB support: RFC1213MIB II, RFC1493, RFC1907, RFC1757, 2819, RFC2021, RFC1398, 1643, 1650, 2358, 2665, RFC2674, 4363, RFC 2233, 2863, RFC 2618, RFC 2620

Connectivity:

• Number of Basic switching RJ-45 Ethernet ports: 24
• Basic switching RJ-45 Ethernet port types: Gigabit Ethernet (10/100/1000)
• Number of SFP module slots: 4
• Fiber Optic Connector: SFP
• Console input: RJ-45

Network:

• Communications Standards: IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad
• 10G Support: No
• Copper Ethernet cabling technology: 10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
• Port Mirroring: Yes
• IP Routing: Yes
• Full duplex: Yes
• Spanning tree protocol: Yes
• Auto MDI/MDI-X: Yes
• Auto-negotiation: Yes
• Link aggregation: Yes
• Flow control support: Yes
• Rate Limiting: Yes
• VLAN Support: Yes
• Virtual LAN features: MAC address-based VLAN, Port-based VLAN, Tagged VLAN, Voice VLAN
• Number of VLANs: 4094

Optical fiber:

• Fiber Ethernet cabling technology: 1000BASE-X
• DATA TRANSMISSION
• Routing/switching capacity: 56 Gbit/s
• Forwarding rate: 41.7 Mpps
• MAC address table: 16000 entries
• Store-and-forward: Yes
• Number of rows: 8
• Number of static routes: 32
• Supports jumbo packages: Yes
• Jumbo packs: 9216
• Stored package memory: 1.5 MB

Security:

• DHCP features: DHCP client
• Access Control List (ACL): Yes
• Access control list rules: 256
• IGMP snooping: Yes
• IP-MAC port binding: Yes
• Authentication: Guest VLAN, MAC-based authentication (Message Authentication Code), Port-based authentication
• BPDU filtering/protection: Yes
• Encryption/Security: 802.1x RADIUS, SNMP, SSH
• SSH/SSL Support: Yes
• Loop protection: Yes
• MULTICAST FEATURES
• Multicast Support: Yes
• Multicast Listener Discovery (MLD) Interception: MLD v1, MLD v2

Design:

• Shelf Mounting: Yes
• Shape: 1U
• Product color: Black, Gray
• LED indicators: Activity, Fan failure, Connection, Dust, Speed
• Number of fans: 2 fan(s)
• Electromagnetic compatibility: FCC A, CE A, VCCI, C-Tick, BSMI, CCC
• Certification: IEC61000-4-5, RoHS

Performance:

• Memory type: DDR3-SDRAM
• Internal memory capacity: 256 MB
• Flash memory size: 32 MB
• Noise level: 52.4 dB

Power management:

• Power supply: AC/DC
• AC input voltage: 100 - 240 V
• AC input frequency: 50 - 60 Hz
• Power consumption (typical): 27.49 W

Put:

• Power over Ethernet (PoE): Yes
• Number of PoE ports: 24

Environmental conditions:

• Operating temperature (TT): -5 - 50 °C
• Temperature limit (storage): -40 - 70 °C
• Operating relative humidity (HH): 10 - 90%
• Non-operating humidity: 5 - 90%
• Heat dissipation: 850.58 BTU/h

Weights and Dimensions:

• Width: 440mm
• Depth: 210mm
• Height: 44 mm
• Weight: 3.86 kg

Reference

DGS-1210-28MP/E
