• 5 10/100/1000Mbps ports allow instant transfer of large files
• Innovative energy-efficient technology reduces energy consumption by up to 57%
• IEEE 802.3x control enables reliable data transfers
• 15K Jumbo frame improves big data transfer performance
• Efficient network monitoring via port mirroring, Loop Prevention and Cable Diagnostics
• Abundant VLAN features improve network security via traffic segmentation
• IGMP Snooping optimizes multicast applications
• Web-based ¹ user interface and utility management simplify setup

Specifications

• Hardware Features
• Protocols and Standards: IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
• Interface: 5 10/100/1000Mbps RJ45 Ports / AUTO Negotiation/AUTO MDI/MDIX
• network media
• 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m)
  EIA/TIA-568 100Ω STP (maximum 100m)
  100BASE-TX: UTP category 5, 5e cable (maximum 100m)
  EIA/TIA-568 100Ω STP (maximum 100m)
  1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
  EIA/TIA-568 100Ω STP (maximum 100m)
• Fans: 0
• Power: 100-240VAC, 50/60Hz
• Power Consumption: Maximum: 2.49W (220V/50Hz)
• Dimensions: 100*98*25 mm

• performance
• Packet Forwarding Rate: 7.4Mbps
• MAC Address Table: 2K
• Packet Buffer Memory: 1.5Mb
• Jumbo Frame: 15Kb

• Software Features
• Service quality
• Supports Port-based/802.1p/DSCP ² priority
  Supports 4 priority queues
  Limit Rate
  Storm Control
• L2 characteristics
• IGMP Snooping V1/V2/V3
  Aggregation Links
  Door Mirroring
  Cable Diagnostics
  Loop Prevention

• VLAN
• Supports up to 32 simultaneous VLANs (from 4K VLAN IDs)
  MTU/Port/Tag VLAN
• Transmission Method: Store-And-Forward

• Others
• Certifications: FCC, CE, RoHS
• Packing Contents:
• TL-SG105E
  Feeder
  Installation Guide
  Resource CD
  rubber feet
• System Requirements: Microsoft® Windows® for running Utility
• Environment:
• Operating Temperature: 0℃~40℃ (32℉~104℉)
  Storage Temperature: -40℃~70℃ (-40℉~158℉)
  Operating Humidity: 10%~90% non-condensing
  Storage Humidity: 5%~90% non-condensing
