ELEGANT AND ULTRA-COMPACT DESIGN

About the size of a credit card, the MS105 can be placed anywhere in your home without taking up too much space. Its fanless design allows it to remain unobtrusive no matter how long it's been running.

EXPANDS THE ETHERNET NETWORK

With five 10/100Mbps Ethernet ports, you can quickly expand your wired network. The MS105 is flexible and fully compatible with computers, printers, IP cameras, smart TVs, video game consoles and more. This makes it perfect for home environments, small offices and even dorm rooms.

EASE OF USE

Forget complicated installation. Simply connect the switch to your TV or computer via an Ethernet cable to immediately expand your wired network. Absolutely no configuration is required.

RELIABLE PERFORMANCE

With Half/Full Duplex and MAC Address Learning technology, the MS105 provides up to 1 Gbps of stable switching bandwidth. All units undergo extensive testing prior to shipment, ensuring the MS105 will provide reliable, uninterrupted connections for years to come.

Specifications:

-External power supply:

-External power adapter

-(Output: 5.0VDC / 0.6A)

-Interface:

-5x 10/100Mbps ports

-automatic negotiation

-Auto MDI/MDIX

Standards and Protocols:

-IEEE 802.3, IEEE 802.3u, IEEE 802.3x

-CSMA / CD

-Number of fans: without fan

Data fees:

-10 / 100Mbps in half-duplex

-20 / 200Mbps in full duplex

- Buffer capacity: 768Kb

- Jumbo Frame: 2KB

- Switching capacity: 1Gbps

-LED: Ethernet (1, 2, 3, 4, 5), Power

-Transfer method: Store and forward

-Dimensions: 82 x 49 x 21mm

Package content:

-Switch MS105

-Energy Adapter

-Quick installation guide
