WATCHDOG GUARANTEES THE UNINTERRUPTED OPERATION OF POE DEVICES

WatchDog PoE continuously monitors the connection status of remote hosts. If an error is detected on the remote PoE device, the PoE switch immediately restarts the device to bring it back to normal operation.

PLUG & PLAY, FANLESS DESIGN

Plug and Play, easy to use, fanless design for silent operation, high quality metal case, sturdy and durable, with long service life, provides better heat dissipation, suitable for most environment.

Main Features:

-Supports IEEE802.3at and IEEE802.3af Standard

-Capable of 120W of PoE output power，up to 32W for one PoE port

-Supports IEEE802.3x full duplex and half duplex flow control

-Supports VLAN and CCTV function

-Panel of lights to monitor the working status and help in fault analysis

-Perfect security mechanism

-Intelligent speed line forwarding

Specifications:

-PoE standard: IEEE802.3af/at

-Interface: 10x 10/100Mbps RJ45 ports

-Key function: CCTV & VLAN

-PoE ports: 1~8

-Total PoE: 120W

-Power supply: 120W

-Maximum PoE per port: 32W

-Indicators: PWR, LNK/ACT, PoE

- Means of network:

-10BASE-T: Category 3, 4, 5 UTP cable(≤100m)

-100BASE-TX: UTP cable category 5, 5e(≤100m)

-MAC Address Table: 8K, Auto Study, Auto Updates

-Jumbo Frame: 1528Bytes

-Packet buffer: 2M bit

-Transfer mode: Store-and-forward

- Packet sending rate: 1.48Mpps

-Dimensions: 220 x 150 x 44 mm

-Weight: >1kg
