Characteristics:

(32) GbE ports, PoE+ RJ45

(16) GbE RJ45 ports

(4) 1G SFP ports

Full 195W PoE availability

1.3" LCM color touchscreen with AR switch management

hardware

Network interface: (48) 10/100/1000 RJ45 ports | (4) 1G SFP Ethernet ports

Management Interface: In-band Ethernet

Total non-blocking transfer rate: 52 Gbps

Switching Capacity: 104 Gbps

forwarding rate: 77.38 Mpps

power method: 100—240 VAC, 50/60 Hz, universal input

Power source: AC/DC, internal, 240W

Supported voltage range: 100—240 V AC

max. power consumption: 45W (excluding PoE output)

ESD/EMP protection: Air: ±16kV, contact: ±12kV

Shock and vibration: Standard ETSI300-019-1.4

Operating temperature: -5 to 40° C (23 to 104° F)

Operating humidity: 10 to 90% non-condensing

Certifications: CE, FCC, IC
