Ubiquiti UniFi Switch Pro 8 POE - (8 RJ45 Ports / 2 SFP Ports - Layer 3 - 120W - PoE+ / PoE++)

• Dimensions: 200 x 248 x 44 mm (7.9 x 9.8 x 1.7")
• Weight: 2.1 kg (4.6 lb)
• Housing Materials: Polycarbonate, metal
• Mounting Material: Polycarbonate

• Management Interface: In-Band Ethernet
• Network Interface: (8) GbE RJ45 ports, (2) 10G SFP+ ports
• PoE Interface: (6) PoE/PoE+ (Pins 1, 2+; 3, 6-), (2) 60W PoE++ (Pair A 1, 2+; 3, 6-) (Pair B 4, 5+; 7, 8-)
• Total Unblocked Throughput: 28 Gbps
• Switching Capacity: 56 Gbps
• Power Method: Universal input, 100—240V AC, 2A Max.
• Power Supply: AC/DC, internal
• Supported Voltage Range: 100—240V AC
• Maximum Power Consumption: 30W (Excluding PoE output)
• Total PoE Available: 120W
• Maximum PoE Power per Port per PSE: PoE: 15W, PoE+: 30W, PoE++: 60W
• PoE Mode Voltage Range: PoE: 44—57V, PoE+: 50—57V, PoE++: 50—57V
• LCM screen: (1) 1.3" touchscreen
• LEDs: RJ45 ports: connection/activity
• Button: Factory reset
• Ambient Operating Temperature: -5 to 45° C (23 to 113° F)
• Ambient Operating Humidity: 10 to 90% non-condensing
• Certifications: CE, FCC, IC

• Layer 2 Features: Ubiquiti, IGMP snooping, STP/RSTP with port-level priorities and deactivation, Port isolation, Storm control, Voice VLAN, Port mirroring, LACP port aggregation, Broadcast/multicast rate limiting, Blocking MAC Address Number, Flow Control, 802.1X Control, Jumbo Frames, Proprietary Loop Protection, DHCP Inspection/Guard, Egress Rate Limit, LLDP-MED, MAC Restricted Port, Device Isolation with ACLs
• Layer 3 Features: DHCP for locally managed networks, DHCP relief, Inter-VLAN routing between networks on the same switch, Static routing between local networks

• UniFi Network: Version 7.5.176 and later

Brand

Ubiquiti

Reference

USW-PRO-8-POE

Stock Online

Sold out

Stock Store

Sold out
