WATCHDOG GUARANTEES THE UNINTERRUPTED OPERATION OF POE DEVICES

WatchDog PoE continuously monitors the connection status of remote hosts. If an error is detected on the remote PoE device, the PoE switch immediately restarts the device to bring it back to normal operation.

PLUG & PLAY, FANLESS DESIGN

Plug and Play, easy to use, fanless design for silent operation, high quality metal case, sturdy and durable, with long service life, provides better heat dissipation, suitable for most environment.

Main Features:

-24 PoE+ 10/100M ports

-2 Gigabit Uplink Ports

-1 SFP 1.25Gbps Slot

-Capacity of 300 Watts PoE

- Compliance with IEEE 802.3at / IEEE 802.3af standard

-Plug & play, simple setup and no configuration required

Specifications:

-Power supply: Built-in AC100~240V power supply

-Interface:

-24x 10/100Mbps PoE RJ45 ports

-2x RJ45 Gigabit Ports

-1x SFP 1.25GbE port

-PoE standards: 802.3af/at

-Consumption: 300W for 24x PoE ports

-Maximum PoE output per port:

-30W (802.3at)

-15.4W (802.3af)

-Switching Capacity: 10.8Gbps

- Means of network:

-10BASE-T: Cat 6 UTP(≤250 meters)

-100BASE-TX: Cat5 or more UTP (≤100 meters)

-1000BASE-TX: Cat5 or more UTP (≤100 meters)

-MAC Address: 2K

-Packet Buffer Memory: 1M

-Packet Forwarding Rate: 8Mbps

-Weight: 1.9 Kg
