LNB Twin Dicom ||

TECHNICAL CHARACTERISTICS:

Input frequency:

 Low Band: 10.70 ~ 11.70 GHz
 High Band: 11.70 ~ 12.75 GHz
Output frequency:

 Low Band: 950 ~ 1950 MHz
 High Band: 1100 ~ 2150 MHz
Local Oscillator Frequency:

 Low Band: 9.75 GHz
 High Band: 10.60 GHz
Noise Figure:

 0.7 dB (typ.)
Gain at 25ºC:

 58 dB (min.) / 65 dB (max.)
Gain Stability:

 ± 0.5 dB / 26 MHz
Cross Polarization Isolation:

 25 dB (typ.)
Local Oscillator Stability:

 ± 1.0 MHz (max.) @ + 25º C
 ± 2.0 MHz (max.) @ -40º C ~ + 60º C
Local noise of the oscillator:

 -50 dBc / Hz @ 1 kHz
 -75 dBc / Hz @ 10 kHz
 -95 dBc / Hz @ 100 kHz
Image Rejection:

 40 dB (min.)
VSWR:

 2: 1 (typ.)
Current consumption:

 160 mA (max.)
Band Change:

 Low Band: 0 kHz
 High band: 22 kHz ± 4 kHz
Voltage - polarization change:

 11.5 ~ 14.0 V Vertical
 16.0 ~ 20.0 V Horizontal
Operating Temperature:

 -40º C ~ + 60º C

Brand

Dicom

Reference

AS0422

Stock Online

Available

Stock Store

Available

Color

Black

No. of LNB Exits

2
